Welcome

CrackMaster Concrete is a full-service foundation repair and waterproofing company serving Chilliwack  Abbotsford, Lower mainland, Vancouver North Vancouver ,West Vancouver and surrounding area.

Our services include:

• Crack Repair - from the inside and outside
• Weeping Tile - interior and exterior
• Sump pump installations
• Waterproofing Membranes



Weeping Tile

A weeping tile is a porous pipe used for underground drainage. The pipe is typically plastic with small slits cut lengthwise into it. It is buried and surrounded by aggregate larger than the slits. The aggregate rocks prevent excessive soil from falling through the slits into the weeping tile. With this arrangement, water in the surrounding soil above the weeping tile flows into the weeping tile. The weeping tile then drains into a storm sewer or a sump pump.

The weeping tile is to be installed so that the top of the product is lower than the bottom of the interior concrete floor. The weeping tile should be connected to a sump pit, located on the interior of the home. The ground water collected in the sump pit can then be removed by a sump pump. The exhausted water can be pumped a safe distance from the home by means of a flexible line or in some areas, into the city storm drains. Care should be taken not to create flooding conditions for adjoining properties.





Sump Pump

A sump pump is a pump used to remove water that has accumulated in a water collecting sump pit, commonly found in the basement of homes. The water may enter via the perimeter drains of a basement waterproofing system, funneling into the pit or because of rain or natural ground water, if the basement is below the water table level.

Sump pumps are used where basement flooding happens regularly and to remedy dampness where the water table is above the foundation of a home. Sump pumps send water away from a house to any place where it is no longer problematic, such as a municipal storm drain or a dry well. Pumps may be connected to the sanitary sewer in older properties. Now, this practice may be against the plumbing code or at least municipal bylaws because it can overwhelm the municipal sewage treatment system.
Usually hardwired into a home's electrical system, sump pumps may have a battery backup. The home's pressurized water supply powers some pumps, eliminating the need for electricity. Since a sump pit may overflow if not constantly pumped, a backup system is important for cases when the main power is out for prolonged periods of time.

There are generally two types of sump pumps: pedestal and submersible. The pedestal pump's motor is mounted above the pit, where it is more easily serviced but also more conspicuous. The submersible pump is entirely mounted inside the pit, and is specially sealed to prevent electrical short circuits.





Waterproofing

In construction, a building or structure needs waterproofing since concrete itself will not be watertight on its own. The conventional system of waterproofing involves 'membranes'. This relies on the application of one or more layers of membrane (available in various materials: e.g., bitumen, silicate, PVC, EPDM etc.) that act as a barrier between the water and the building structure, preventing the passage of water. However, the membrane system relies on exacting application, presenting difficulties. Problems with application or adherence to the substrate can lead to leakage.

Over the past two decades, the construction industry has had technological advances in waterproofing materials, including integral waterproofing systems as well as more advanced membrane materials.
Integral systems work within the matrix of a concrete structure, giving the concrete itself a waterproof quality. There are two main types of integral waterproofing systems: the hydrophilic and the hydrophobic systems. A hydrophilic system typically uses a crystallization technology that replaces the water in the concrete with insoluble crystals. Various brands available in the market claim similar properties, but not all can react with a wide range of cement hydration by-products, and thus require caution. Hydrophobic systems use fatty acids to block pores within the concrete, preventing water passage.

New membrane materials seek to overcome shortcomings in older methods like PVC and HDPE. Generally, new technology in waterproof membranes relies on polymer based materials that are extremely adhesive to create a seamless barrier around the outside of a structure.



Basement waterproofing
Basement waterproofing once completed becomes very difficult since the water pressure is from the negative side (from outside coming inside), the difficulty arises when no membrane can withstand any hydrostatic pressure from within the substrate hence they fail. The only proven method is by a process known as in-depth crystallization waterproofing system. Here the active chemicals with water penetrate into the structure by reverse osmosis and produces a catalytic action where the by-products of the structure come together to form non-soluble crystals within the capillary pores of the structure and effective blocks water transmission. Water may enter a basement through various means including through joints, walls, or floors. Various basement waterproofing systems address these problems. There are many systems available of varying cost, effectiveness, and installation invasiveness. Specially used membranes in this field are protection board sheets. Basement waterproofing may be done internally and externally. Because basement foundations can be brick, block, concrete, and even wood, it is important to pick the right waterproofing system for the right foundation.
